PA194I-AX4 74*74mm three phase digital display panel mount current meter

FOB Reference Price:Get Latest Price
US $50.5-75.8 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
Elecnova
Model Number:
PA194I-AX4
Display Type:
Digital Only
Measuring Range:
0~9999
Accuracy Class:
0.2/0.5
Supply Voltage:
AC 80~270V
Operating Temperature:
-40~+70℃
Dimensions:
74*74mm
Product name:
74*74mm three phase digital display panel mount current meter
Certificate:
CE ISO9001
Warranty:
2 years
Usage:
Amp Measurement
Type:
Digital Ammeter
Phase:
3 Phase
Frequency:
45~65Hz
Communication:
RS-485/Modbus/2-wire
Storage temperature:
-40~85℃
Relative humidity:
≤93%RH
Supply Ability
Supply Ability:
30000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
1 pc/ctn, standard export packing, or according to customer's requirements
Port
Shanghai



1.Product introduction



PA19 series digital display ammeters are used to measure single phase or three phase AC current in low voltage distribution system. They are equipped with analog output, relay output, digital input and communication supporting Modbus-RTU protocol. Their transmitting ratio also can be changed through programming. There are different choices of outline size for this kind of meters. So they are suitable to replay analog pointer ammeters.

This series digital display AC voltage meters have high environment adaptability because their working temperature range is -40~70 and EMC better than III level. They can be applied in control systems, distribution automation systems, industrial automation systems and intelligent buildings.



2.Product display






3.Technical specification



Accuracy

 0.2%, 0.5%(defaulted)

Data refresh rate

1s

Input

Rated value

AC 1A, 5A



Range

(0.005 ~ 1.2)In



Overload

Continuous 1.2In,Instantaneous 10In/5s



Frequency

45~65Hz

Power supply

Working range

AC 80~270V (50/60Hz), DC 80~270V,DC 24V



Consumption

≤5VA

Digital input

Dry contact mode

Relay output

Contact capacity (resistive):AC 5A/250V, DC 5A/30V

Analog output

Current output

DC 4~20mA, 0~20mA etc., load ≤350Ω



Voltage output

DC 0~5V, 1~5V etc., load ≥20kΩ

Communication

RS485 interface,Modbus-RTU protocol,baud rate 2400~9600bps

Environment

Protection degree

Panel IP64, case IP20

Working temperature

-40~70℃(LED), -25~70℃(LCD)

Storage temperature

-40~85℃

Relative humidity

≤93%RH

Insulating ability

Between power and input or output≥AC2kV,

Between input and output≥AC1kV

Altitude

2500m
