PZ194U-9X4 96*96mm panel mount three phase digital LED AC voltmeter

FOB Reference Price:Get Latest Price
US $50.5-75.8 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
SFERE
Model Number:
PZ194U-9X4
Display Type:
Digital Only
Measuring Range:
AC 100V, 220V, 380V
Accuracy Class:
0.2/0.5
Operating Temperature:
-40~+70℃
Dimensions:
96*96mm
Product Name:
PZ194U panel mount three phase digital LED AC voltmeter
Certificate:
CE ISO9001 ISO14001
Type:
Digital Panel Meter
Usage:
Industrial Measurement
Display:
LED Intelligent Digital
Communication:
RS485 Modbus-RTU
Phase:
3 Phase
Frequency:
45~65Hz
Warranty:
2 Years
Service:
OEM ODM
Supply Ability
Supply Ability:
20000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
1 pc/ctn, standard export packing, or as per client's requirements
Port
Shanghai port

1 Product Description1

1.Product display




2.Product introduction

This series digital display voltmeters are used to measure single phase or three phase AC voltage in low voltage distribution system. They are equipped with analog output, relay output, digital input and communication supporting Modbus-RTU protocol. Their transmitting ratio also can be changed through programming. There are different choices of outline size for this kind of meters. So they are suitable to replace analog pointer voltmeters.

This series digital display AC voltmeters have high environment adaptability because their working temperature range is -40~70 and EMC better than III level. They can be applied in control systems, distribution automation systems, industrial automation systems and intelligent buildings.



3.Technical specification



Accuracy

0.5%(defaulted), 0.2%

Display mode

LED or LCD

Data refresh rate

1s

Input

Rated value

AC 100V, 220V, 380V



Overload

continuous 1.2Un



Frequency

45~65Hz

Power supply

Working range

AC 80~270V  50/60Hz, DC 80~270V



Consumption

≤5VA

Digital input

Dry contact mode

Relay output

Contact capacity (resistive):AC 5A/250V, DC 5A/30V

Analog output

Current output

DC 4~20mA, 0~20mA, 0~5mA etc.,

If 4~20mA or 0~20mA,load≤350Ω

If 0~5mA,load≤1 kΩ



Voltage output

DC 0~5V, 1~5V, 0~10V etc.,load≥20kΩ

Communication

RS485 interface,Modbus-RTU protocol,baud rate 2400~9600bps

Environment

Working temperature

LED:-40~70   LCD:-25~70

Storage temperature

-40~85

Relative humidity

≤93%RH

Pollution degree

2

Measurement type

CAT III

Insulating ability

Between power and input or output≥AC2kV,

Between input and output≥AC1kV

Altitude

2500m
